Xtreme Wire and Cables
India’s #1 Cable Manufacturer.
North American Distribution by XIS.
XIS is the authorized North American distributor for Polycab — India’s #1 wire and cable manufacturer. Through this strategic partnership, XIS brings Polycab’s proven UL-listed cable solutions to the U.S. and Canadian markets, delivering world-class quality, safety, and performance backed by decades of Polycab’s engineering excellence. Every Polycab cable distributed by XIS is produced in state-of-the-art manufacturing facilities and rigorously tested to meet or exceed Underwriters Laboratories (UL) standards.
UL 1569 Type MC Cable
Polycab’s UL 1569 Type MC (Metal Clad) cable, available exclusively through XIS in North America, is a versatile, factory-assembled cable designed for power, lighting, control, and signal circuits in commercial, industrial, and institutional environments. Featuring an interlocking aluminum armor over individually insulated conductors, Polycab Type MC cable delivers superior mechanical protection, simplified installation, and reliable long-term performance — eliminating the need for separate conduit in many applications.
Construction and Design
| Component | Specification |
|---|---|
| Conductors | Annealed bare copper, available in solid or stranded configurations |
| Insulation | THHN/THWN-2 rated PVC/Nylon, 90°C dry / 75°C wet |
| Armor | Aluminum interlocking armor for mechanical protection |
| Inner Jacket | PVC inner jacket where applicable |
| Grounding | Full-size or reduced-size equipment grounding conductor |
Features
- UL Listed to UL 1569 standard
- Suitable for branch circuit wiring in commercial, industrial, and institutional buildings
- Rapid installation with no conduit required — reduces labor and material costs
- Interlocking armor provides excellent crush and impact resistance
- Available in a range of conductor sizes and configurations
- NEC Article 330 compliant
- Suitable for installation in cable trays, direct burial where rated, and open/concealed runs
Applications
- Commercial office buildings and retail spaces
- Healthcare facilities
- Educational institutions
- Industrial plants and manufacturing facilities
- Data centers and IT infrastructure
- Multi-family residential construction
UL 83 THHN / THWN / THWN-2 Building Wire
Manufactured by Polycab and distributed by XIS, these THHN/THWN/THWN-2 conductors represent the gold standard in thermoplastic building wire for general-purpose circuit wiring in conduit and raceway systems. Engineered to meet or exceed UL 83 requirements, Polycab building wire combines a heat-resistant PVC insulation system with a tough nylon outer jacket, delivering reliable electrical performance, mechanical durability, and chemical resistance across a broad range of installations.
Construction and Design
| Component | Specification |
|---|---|
| Conductors | Annealed bare copper, solid (14–10 AWG) or stranded (14 AWG and larger) |
| Insulation | Heat-resistant thermoplastic PVC |
| Jacket | Nylon (polyamide) outer covering for abrasion and chemical resistance |
| Temperature Ratings | 90°C dry (THHN), 75°C wet (THWN), 90°C dry / 75°C wet (THWN-2) |
Features
- UL Listed to UL 83
- Dual-rated THHN/THWN-2 for maximum installation versatility
- Nylon jacket provides superior resistance to gasoline, oil, and common solvents
- Compact design for easy pulling through conduit and raceways
- Color-coded for rapid circuit identification
- Available in a comprehensive range of sizes from 14 AWG to 1000 kcmil
- Sunlight resistant where marked
- Suitable for use at 600V maximum
Applications
- General-purpose branch circuit wiring
- Power distribution in commercial and industrial buildings
- Machine tool wiring
- Control circuits
- Conduit and raceway installations per NEC Article 310
- Appliance wiring
UL 493 UF-B Underground Feeder Cable
Polycab’s UF-B (Underground Feeder and Branch Circuit) cable, available through XIS, is a rugged, moisture-resistant cable specifically engineered for direct burial applications without the need for conduit. Polycab UF-B cables feature solid thermoplastic insulation molded directly around the conductors, forming an integral moisture and corrosion barrier that ensures reliable performance in underground, wet, and outdoor environments.
Construction and Design
| Component | Specification |
|---|---|
| Conductors | Annealed bare copper, solid or stranded |
| Insulation | Integral PVC insulation with moisture-resistant outer jacket |
| Construction | Flat, parallel-lay design with insulation extruded directly over and between conductors |
| Ground | With or without equipment grounding conductor |
Features
- UL Listed to UL 493
- Designed for direct burial without conduit
- Moisture, fungus, and corrosion resistant
- Sunlight resistant
- Suitable for wet, dry, and direct burial locations
- Available in 2-conductor and 3-conductor configurations with ground
- Rated for 600V maximum
- NEC Article 340 compliant
Applications
- Underground feeder and branch circuit wiring
- Outdoor landscape lighting circuits
- Residential outdoor circuits including pools, sheds, and detached garages
- Agricultural and farm wiring
- Direct burial power distribution
- Wet location interior wiring
UL 1072 — Medium Voltage (MV) Power Cable
Polycab manufactures a comprehensive range of UL 1072-listed Medium Voltage power cables for primary power distribution across utility, industrial, and commercial infrastructure. Available through XIS in North America, the Polycab MV cable portfolio spans 17 product configurations across two voltage classes, two conductor types, two insulation technologies, and two insulation levels — providing engineers and specifiers with precise solutions for every medium voltage application. All Polycab UL 1072 cables are single-core, tape-shielded, PVC-jacketed designs manufactured in state-of-the-art facilities.
Complete UL 1072 Product Matrix
| Product Designation | Voltage Class | Conductor | Insulation | Insulation Level |
|---|---|---|---|---|
| Polycab MV 15kV Cu TR-XLPE 100% | 15 kV | Copper | TR-XLPE | 100% |
| Polycab MV 15kV Cu TR-XLPE 133% | 15 kV | Copper | TR-XLPE | 133% |
| Polycab MV 15kV Cu EPR 100% | 15 kV | Copper | EPR | 100% |
| Polycab MV 15kV Cu EPR 133% | 15 kV | Copper | EPR | 133% |
| Polycab MV 15kV AL TR-XLPE 100% | 15 kV | Aluminum 8000 Series | TR-XLPE | 100% |
| Polycab MV 15kV AL TR-XLPE 133% | 15 kV | Aluminum 8000 Series | TR-XLPE | 133% |
| Polycab MV 15kV AL EPR 100% | 15 kV | Aluminum 8000 Series | EPR | 100% |
| Polycab MV 15kV AL EPR 133% | 15 kV | Aluminum 8000 Series | EPR | 133% |
| Polycab MV 35kV Cu TR-XLPE 100% | 35 kV | Copper | TR-XLPE | 100% |
| Polycab MV 35kV Cu TR-XLPE 133% | 35 kV | Copper | TR-XLPE | 133% |
| Polycab MV 35kV Cu EPR 100% | 35 kV | Copper | EPR | 100% |
| Polycab MV 35kV Cu EPR 133% | 35 kV | Copper | EPR | 133% |
| Polycab MV 35kV AL TR-XLPE 100% | 35 kV | Aluminum 8000 Series | TR-XLPE | 100% |
| Polycab MV 35kV AL TR-XLPE 133% | 35 kV | Aluminum 8000 Series | TR-XLPE | 133% |
| Polycab MV 35kV AL EPR 100% | 35 kV | Aluminum 8000 Series | EPR | 100% |
| Polycab MV 35kV AL EPR 133% | 35 kV | Aluminum 8000 Series | EPR | 133% |
| Polycab MV 15kV Cu XLPE 100% | 15 kV | Copper | XLPE | 100% |
Insulation Technologies
TR-XLPE (Tree-Retardant Cross-Linked Polyethylene): Polycab’s TR-XLPE insulated MV cables offer superior resistance to electrochemical and water treeing — the leading cause of insulation degradation in underground MV cables. TR-XLPE provides extended cable life, reduced maintenance, and reliable performance in wet and direct burial environments. MV-105 rated for continuous operation at 105°C.
EPR (Ethylene Propylene Rubber): Polycab EPR-insulated MV cables provide outstanding flexibility, moisture resistance, and thermal stability. EPR insulation is well-suited for applications requiring frequent bending, confined-space installation, or exposure to moisture and chemical environments. MV-105 rated for continuous operation at 105°C.
Insulation Levels
Polycab MV cables are available in both 100% and 133% insulation levels per ICEA/AEIC standards. 100% insulation level is appropriate for grounded systems where ground fault detection and clearing occurs within one minute. 133% insulation level is recommended for systems where fault clearing time may exceed one minute, or for ungrounded or resistance-grounded systems requiring additional insulation margin.
Construction and Design
| Component | Specification |
|---|---|
| Conductor (Copper) | Circular Class B compressed annealed bare copper per ASTM B3 and ASTM B8 |
| Conductor (Aluminum) | Class B compact stranded 8000 series aluminum alloy per ASTM B800 and ASTM B836 |
| Conductor Screen | Extruded semi-conductive compound |
| Insulation | TR-XLPE, EPR, or XLPE compound per product variant |
| Insulation Screen | Extruded semi-conductive compound triple-extruded with conductor screen and insulation |
| Metallic Shield | Helically applied copper tape with 25% overlap |
| Outer Jacket | Extruded PVC, black |
| Bending Radius | 16× overall diameter |
Temperature Ratings
| Condition | Rating |
|---|---|
| Continuous Operating | −35°C to 105°C |
| Emergency Overload | 140°C |
| Short Circuit | 250°C |
Features
- UL Listed to UL 1072
- Available in 15kV and 35kV voltage classes
- Copper and Aluminum 8000 series alloy conductor options
- TR-XLPE, EPR, and XLPE insulation options
- 100% and 133% insulation levels
- MV-90 and MV-105 temperature ratings
- Flame retardant — meets UL 1685/FT4 vertical tray fire propagation and smoke release requirements (1/0 AWG and larger)
- IEEE 1202 vertical tray flame test compliant (1/0 AWG and larger)
- Sunlight resistant, corona resistant, and moisture resistant
- Lead-free construction
- Suitable for wet and dry locations, conduits, ducts, troughs, trays, and direct burial
Applications
- Utility primary power distribution networks
- Underground residential distribution (URD)
- Industrial plant and substation feeders
- Commercial campus power distribution
- Data center primary power infrastructure
- Renewable energy and solar farm collection circuits
- EV charging infrastructure
- Mining and heavy industrial power systems
- Underground distribution in municipal and transportation projects
Standards and Compliance
- UL 1072 — Medium Voltage Power Cable
- ICEA S-97-682 — Utility Shielded Power Cable
- ICEA S-93-639 — Shielded Power Cable Rated 5 Through 46 kV
- UL 1685/FT4 — Vertical Tray Fire Propagation and Smoke Release
- IEEE 1202 — Vertical Tray Flame Test
- CSA C68.10 — Shielded Power Cable for Commercial and Industrial Application, 5–46 kV
- UL 2556 — Wire and Cable Test Methods
- UL 1581 — Reference Standard for Electrical Wires, Cables, and Flexible Cords
- ASTM B3, B8 for copper conductors / ASTM B800, B836 for aluminum conductors
Polycab Quality — XIS Service
All cables in the XIS product range are manufactured by Polycab in state-of-the-art facilities and undergo rigorous quality assurance protocols, including in-process testing, final product verification, and independent third-party evaluation by Underwriters Laboratories. Polycab maintains active UL certification across its cable product lines, with ongoing follow-up inspections and surveillance audits to ensure consistent product quality and regulatory compliance at every stage of manufacturing.
XIS provides dedicated North American distribution, technical support, and customer service for the full range of Polycab UL-listed cables. Whether you require standard catalog products or custom-engineered cable configurations, the XIS team is ready to support your project requirements.
